Description
Features:
- 4-Channel full duplex passive copper cable
- Data Rate 106.25 Gb/s PAM4 per lane
- Compliant with OSFP MSA, CMIS, and IEEE 802.3
- Low power consumption less than 0.1W
- LSZH’s cable outer layer material
- Management interface with I²C EEPROM
- Enhance EMI/EMC Performance
- CE/ROHS/FCC compliant
Specs:
| Model NO. | OSFP-400G-CUxM | OSFP-2QSFP56-CUxM | OSFP-QSFP112-CUxM |
| From Factor | OSFP to OSFP | OSFP to 2QSFP56 | OSFP to QSFP112 |
| Data Rate | 400Gbps | 2*200Gbps | 400Gbps |
| Reach | 0.5~3M | 0.5~3M | 0.5~3M |
| AWG Cable | 30/26AWG | 30/26AWG | 30/26AWG |
| Max. Power Consumption | 0.1W | 0.1W | 0.1W |
| Supply Vlotage | 3.3V | 3.3V | 3.3V |
| Commercial Temperature | 0°C to 70°C | ||
| Protocol | Ethernet, IEEE 802.3db, IEEE 802.3ck | ||
